Reliable Ground Penetrating Radar (GPR) Rentals
![About us UL square.jpg](https://static.spacecrafted.com/d37cd3b4629c4b529ef56b39de638e8b/i/c3c4983d240e4762b07cc1c0684eaa48/1/4SoifmQp45JMgBnHghiDJ/About%20us%20UL%20square.jpg)
Ensure your project's success with TerraProbe’s advanced Ground Penetrating Radar (GPR) rental services in Vancouver. Our state-of-the-art GPR equipment is available for short-term and long-term rentals, catering to various needs including construction, environmental assessments, and archaeological surveys. With TerraProbe, you get access to the latest technology combined with expert support, ensuring accurate subsurface imaging and data collection. No matter what your project, our flexible rental plans and competitive pricing make it easy to integrate top-tier GPR capabilities into your workflow. Contact us today to learn more about our GPR rental options and how we can assist with your next project.
Our Inventory
![IDSGeoRadar_Stream DP_800x428_01.jpg](https://static.spacecrafted.com/d37cd3b4629c4b529ef56b39de638e8b/i/d2d7c04d4bdc472584db8eb3b63a8da4/1/4SoifmQp45JMgBnHm9g4L/IDSGeoRadar_Stream%20DP_800x428_01.jpg)
IDS Stream-DP
Best for: Real-time 3D mapping of underground utilities.
Deeper range compared to any other solution available on the market.
Stream DP can be efficiently deployed by a single user thanks to its light weight (max. 20kg per part) and its compact size that fits in a standard vehicle (116cmX82cm).
System specifications:
- 30 channels (19VV+11HH)
- Positioning: Integrated Encoder and PPS; external GPS and TPS
- Max. Acquisition Speed: 14 km/h (8.7 mph)
- Scan width: 83 cm
- System size: 116X82 cm
- Total weight: 42 kg (92.6 lb)
- Environmental: IP65
![Stream C_400x219.jpg](https://static.spacecrafted.com/d37cd3b4629c4b529ef56b39de638e8b/i/e9b1a6150c4741629d991674c9246105/1/4SoifmQp45JMgBnHm9g4L/Stream%20C_400x219.jpg)
IDS Stream-C
Best for: real-time 3D mapping of underground utilities and features. Thanks to the increased level of accuracy, provided by a massive antenna array, Stream C is able to detect pipes and cables automatically.
*Equipment also available for sale. Rental fees can be applied to purchase
System Specifications:
- Positioning: integrated encoder and/or GPS/Total station
- Max. Acquisition Speed: 5km/h (3,1 Mph)
- Scan width: 96 cm
- Polarization: HH and VV
- Total weight: 95kg (209 Ibs)
- Environmental: IP65
![IDSGeoRadar_c-thrue_800x428_2024.jpg](https://static.spacecrafted.com/d37cd3b4629c4b529ef56b39de638e8b/i/c61fb77b10eb424a81b7535522b2bba6/1/4SoifmQp45JMgBnHm9g4L/IDSGeoRadar_c-thrue_800x428_2024.jpg)
IDS C-Thrue
Best for: quickly locating rebars, voids, post-tension cables, cavities, conduits, and any other objects buried in the structure before cutting or drilling into the concrete.
C-thrue is an easy-to-use and robust solution to see through concrete structures and reveal true data.
System Specifications:
- Sensor frequency: 2.0 GHz
- Polarization: Configuration HH and VV
- Depth range: 0-100 cm (0-40 in.)
- Connectivity: LAN to Remote control
- Display modes: B-Scan and C-scan
- Positioning system: Virtual Pad
- Size: 28.5x20x16 (cm) - 11.2x8.6x6.3 (in.)
- Weight: 2.4 kg (5 lb) with battery
- Battery: Li-ion battery, 15V, 3.2Ah
- Max operating time: 3-hour runtime Environmental: IP65
- Compliant with: CE, FCC, IC
![IDS GeoRadar_Chaser XR_03_2480x750.png](https://static.spacecrafted.com/d37cd3b4629c4b529ef56b39de638e8b/i/d6c1926b19d84b23b6f399c1354420c6/1/4SoifmQp45JMgBnHm9g4L/IDS%20GeoRadar_Chaser%20XR_03_2480x750.png)
IDS Chaser XR
Best for: wider range of applications from environmental assessment to archaeological research to manmade structure investigations.
System Specifications:
- Sensor frequency: 80 MHz-1500 MHz
- Size: 41x41x19 cm (16x16x7.4 in.)
- Polarization: Configuration HH and VV
- Connection: LAN or WiFi
- Compliant with: CE, FCC, IC Size: 41x41x19 cm (16x16x7.4 in.)
- Weight: 4.8 kg (10.6 lb) without batteries
![team-removebg-preview.png](https://static.spacecrafted.com/d37cd3b4629c4b529ef56b39de638e8b/i/ccb84074ca8e46ab9bb9da69c6e7cbab/1/GCuCv726gZycFxatR9d99n/team-removebg-preview.png)
Ask about our purchase program!
Some rental equipment is available for sale. Get in touch below for more information.
Services we offer with your rental
Data processing and analysis using IQ-maps / Geolitics
If you're renting a GPR system, especially a muti-antenna array, to deliver a project that requires processing the data collected in the field, but don't want to invest in the software necessary, Decifer GPR Technicians are available to complete your project data processing and deliver the results you need to present to your customers. Ask about adding this service to any of your GPR rentals.
Questions?
For questions about our rental equipment, or for a custom quote, please get in touch below.
